• Meios de sopro B170 45-90μm B205 0-63μm B400 30-63μm do grânulo cerâmico para implantes ortopédicos
  • Meios de sopro B170 45-90μm B205 0-63μm B400 30-63μm do grânulo cerâmico para implantes ortopédicos
Meios de sopro B170 45-90μm B205 0-63μm B400 30-63μm do grânulo cerâmico para implantes ortopédicos

Meios de sopro B170 45-90μm B205 0-63μm B400 30-63μm do grânulo cerâmico para implantes ortopédicos

Detalhes do produto:

Lugar de origem: CHINA
Marca: Zirnano
Certificação: ISO9001,ISO14001
Número do modelo: B20-B505

Condições de Pagamento e Envio:

Quantidade de ordem mínima: 100KGS
Preço: Negotiable
Detalhes da embalagem: 12.5kgs/barrel, a caixa de 25kgs (2 tambores) /paper, ou 25kgs barrels +pallet
Tempo de entrega: 3-5 dias após a ordem confirmada
Termos de pagamento: L/C, T/T, Western Union, MoneyGram
Habilidade da fonte: 200mts pelo mês
Melhor preço Contato

Informação detalhada

Mercadoria: Grânulos cerâmicos Nome do produto: Meios de sopro cerâmicos
forma: Forma redonda contínua Densidade de maioria: 2.3g/cm3
Gravidade verdadeira: 3.85g/cm3 Dureza de Vicker: ≥700HV
Sphericity: ≥0.8 Amostra grátis: Disponível
Realçar:

B170 Ceramic Bead Blasting Media

,

90μM Ceramic Bead Blasting Media

,

Orthopedic Implants Ceramic Blasting Media

Descrição de produto

Ceramic Blasting Media B170 45-90μm B205 0-63μm B400 30-63μm for Orthopedic Implants



1. Product Description of Ceramic Blasting Media

Ceramic Beads selects the high quality zircon sand as main raw material,then fused in arc furnace under

high temperature over 2000 degrees,then made into different microbeads through special technology.

Ceramic beads has medium density and high hardness,which can provide high impact speed in blasting

process,so it is one ideal choice for surface sandblasting and shot peening,especially suitable for titanium

parts.



2. Main Technical Data of Ceramic Beads

Commodity Name Chemical Index Physical Index
Ceramic Blasting Beads

ZrO2 60-66%

SiO2 25-30%
Al2O3 7-13%

Vickers Hardness ≥700 HV
True Specific Gravity ≥3.85 g/cm3
Bulk Density≥2.3g/cm3
Particle Size B20: 0.600-0.850mm
B30:0.425-0.600mm
B40:0.250-0.425mm
B60:0.150-0.300mm
B80:0.125-0.212mm
B100:0.106-0.180mm
B120:0.063-0.125mm
B150:0.000-0.125mm
B170:0.045-0.090mm
B205: 0.000-0.063mm
B400: 0.030-0.063mm
B505: 0.010-0.030mm
Special specification can be customized





3. Main Applications of Ceramic Blasting Media

Surface finish for hardware industries: hardware parts,springs,motor casing,door handles,lock cylinder etc.

Surface cleaning for molds industries: glass-bottle molds,tire molds,rubber molds etc

Surface finishing for mechnical parts,Cylinder head,artifical limb & joints,gears,glasses frames etc

Deburring for electronic & plastics industries: electronic circult board,plastic parts...

Surface strengthening treatment for automotive industries: gear-box built-in parts,Turbine....

Meios de sopro B170 45-90μm B205 0-63μm B400 30-63μm do grânulo cerâmico para implantes ortopédicos 0

Surface finishing for golf head,golf club...



4. Why choose our zirnano Ceramic Beads?

Higher Cleanliness

Zirnano ceramic beads are mede by the special technology,all the ceramic beads are screened more than

six times and blow-cleaning under high temperature,which provides higher clearliness and ensures it to be

work normally in humid weather;



More competitive price/performance ratio

Zirnano ceramic beads has almost the same particle size distribution and blasting effect as the one of Zirblast,

while price is more competitive,since our plant located in mountain areas,the environmental cost and labor

cost is cheaper.



Stable quality & Prompt delivery

Our ceramic beads is made by high quality zircon sand according to stricter formula ratio,all the shipment will

be sampled and tested before loading. Equipped with the most advanced production line and management

system,we can delivery the goods in time.



Stable suppliers of famous company

We are the stable supplier of Kumichel,Samsung Electronics,Foxconn...



5. Questions and Answers:

Q: Are you manufacturer of ceramic beads?

A: Yes,our ceramic beads plant loacted in Shanxi,China



Q:How to place one order?

A:Please click one of our products,then send us one inquiry email, we will reply you immediately after receiving it.



Q: We use galss beads 150# for stainless steel blasting in the past,can I use ceramic beads to replace it?

A: Yes,ceramic beads B120 (63-125μm) can replace galss beads 150# to blast stainless steel products,it will

achieve smooth bright satin finish.



Q: Which specification is more popular?

A: Ceramic beads B40,B60,B120,B205 is the popular specification.



Q:How about the delivery method?

A: If order quantity less than 100kgs,delivery by Air Express is the most quick and reasonable way.

For order quantity more than 100kgs,we will delivery it by sea way.



Q: How about the precautions when I use the ceramic beads at first time?

A:it is suggested to open 1/3 to 1/2 vest of dust collector,since ceramic beads need the wind to be recycled in the

blasting process.



Q: Is ceramic beads recyclable?

A:Yes,ceramic beads is recyclable,it can be blasted 70-90 times in the blasting process generally.



Q:Is it easy to be broken down in the blasting process?

A:No,it is not easy to be broken down,since it has dense crystal structures and high mechnical strength.
